Synergy Audio WFO8.4D 4-Channel Amplifier

$459.99
$459.99 $499.99
Save $40.00 Sold out
Shipping calculated at checkout.

Synergy Mobile Audio WFO 8.4D, 4 Channel Amplifier

WFO 8.4D Specs:

  • Power @ 4 Ohm: 200w x 4 @ 14.4v
  • Power @ 2 Ohm: 320w x 4 @ 14.4v
  • Power @ 4 Ohm Bridged: 630w x 2 @ 14.4v
  • Frequency Response: 10hz – 35khz
  • Signal to Noise Ratio: >100db
  • Subsonic Filter: 10Hz - 500Hz
    • Channels 1/2 – 10hz – 500hz
    • Channels 3/4 – 10hz – 500hz
  • Low Pass Filter: (x1, x10)
    • Channels 1/2 – 50(500)Hz – 800(8K)Hz
    • Channels 3/4 – 50(500)Hz – 800(8K)Hz
  • High Pass Filter: (x1, x10)
    • Channels 1/2 – 20(200)Hz – 800(8K)Hz
    • Channels 3/4 – 20(200k)hz – 800(8k)hz
  • Bandpass Capable
  • Operating Voltage: DC 8V-16V
  • Input sensitivity 8V – 0.2V
  • THD @ 4ohm: < 0.1%
  • Fuse Rating: 250A
  • 0 gauge power and ground inputs
  • 8 gauge speaker inputs
  • Dimensions: 300mm x 239mm x 68.5mm


All WFO series amplifier feature:

  • Custom high mass, thermally optimized aluminum heat sink casing with removable center insert for installation integration.
  • Overbuilt power supplies and output sections utilizing high grade components
  • Heavy duty double sided through hole PCB’s with thick solid copper heavy duty traces
  • Panel locking Tiffany RCA inputs/outputs
  • Single, Double and Triple 1/0 gauge nickel plated power and ground inputs
  • Nickel plated 8 gauge speaker outputs
  • Fully linkable/strappable (Mono-block)
  • Input sensitivity 8V – 0.2V
  • +18db Remote Gain control
  • Multi-way fully intelligent circuitry for maximum protection
