Rockford Fosgate Power Series T600-4 4-Channel Amplifier

$599.99
$599.99 $649.99
Save $50.00 Sold out
Shipping calculated at checkout.

The T600-4 amplifier offers the perfect balance of power output and compact design required for high performance audio systems. The 4-channel configuration allows fine tuning adjustments between front stage component systems and rear surround speakers. The built-in crossover also allows the rear channels to be configured for running one or two subwoofers.



FEATURES AT A GLANCE

  • MOSFET output stage
  • 4 Gauge power/ground connectors
  • 2/4 channel input switch
  • 24dB/octave crossover
  • Audiophile grade speaker connections
  • MOSFET power supply
  • RCA pass-thru outputs
  • 2-Year Warranty
Cta-2006 Compliant

Number of Channels
4
Total Power
(Sum of Rated Power)
600 Watts RMS
Rated Power
(RMS Continuous Power)
100 Watts x 4 @ 4-Ohm
150 Watts x 4 @ 2-Ohm
300 Watts x 2 @ 4-Ohm Bridged
2-Ohm x 2 Bridged Stable
Dynamic Power
(PVC/PowerCube®)
Front Channels
139 Watts x 2 @ 4-Ohms 0° Res
236 Watts x 2 @ 2-Ohms 0° Res

Rear Channels
140 Watts x 2 @ 4-Ohms 0° Res
236 Watts x 2 @ 2-Ohms 0° Res
Bridgeable
Yes
Frequency Response
20Hz to 20kHz +/- 1dB
Input Sensitivity
150 mV to 4 V
Circuit Topology Class
Class A/B
Efficiency (average)
70% @ 4-Ohm
64% @ 2-Ohm
Total Harmonic Distortion (THD+Noise)
4-Ohm: <1.0%
2-Ohm: <1.0%
Signal Input
Front Low level: 1 RCA pair
Rear Low level: 1 RCA pair
Input Switch: 2CH / 4CH
Signal Output
Low Level: 1 RCA pair
Tone Controls
Front Channels - Punch EQ
Treble: 0dB to +12dB @ 12kHz
Bass: 0dB to +18dB @ 45Hz

Rear Channels - Punch EQ
Treble: 0dB to +12dB @ 12kHz
Bass: 0dB to +18dB @ 45Hz
Crossover Controls
Front High-Pass (HP): 50-500Hz 24dB/octave Butterworth
Front Low-Pass (LP): 50-500Hz 24dB/octave Butterworth
Rear High-Pass (HP): 50-500Hz 24dB/octave Butterworth
Rear Low-Pass (LP): 50-500Hz 24dB/octave Butterworth
Remote Controls
Optional Remote Punch EQ
(overrides rear channel built-in Punch EQ)
Visual Indicators
Power
Thermal
Protect
Power Wire Gauge
4 AWG
Power Input Connector
Block
Speaker Wire Gauge
8 AWG to 18 AWG
Speaker Output Connector
Screw terminal barrier strip
Cooling
Convection
Heatsink

Operating Voltage
9 - 16 VDC
Recommended Fuse
(not included)
80 A
Average Current Draw (13.8V Music)
40 A
Max. Current Draw (13.8V Sinewave)
80 A
Suggested Alternator
75 A
Included In The Box

Dimensions (H x W x D)
2.14 x 8.14 x 14.91 (in)
5.42 x 20.68 x 37.86 (cm)
Shipping Weight
12.00 Lbs. (5.44 Kg.)
