Rockford Fosgate Punch P1000X2 2-Channel Amplifier

$499.99
$499.99 $529.99
Save $30.00 Sold out
Shipping calculated at checkout.

The P1000X2 is an excellent way to PUNCH up your sound system without monopolizing your entire trunk - that way you have more room for subs! With its massive output stage, this amplifier is best suited for driving a pair of 8-ohm SVC subwoofers or four 2-ohm DVC subwoofers. Remember to utilize the recommended power and speaker cables to optimize power delivery.



FEATURES AT A GLANCE

  • 12dB/octave Butterworth crossover
  • Features C.L.E.A.N. Set-up
  • High level input capable with Auto Turn-On circuit
  • On-board Punch EQ with +18dB boost @ 45Hz
  • Optional remote Punch Level Control (PLC2) ready (w/ input clip indicator)
  • RCA pass-thru outputs
  • Short circuit protection
  • Over current protection
  • Cast aluminum heatsink
  • Muted turn on
  • Stealth top mounted control panel
  • 1 Year Warranty
Cta-2006 Compliant

Number of Channels
2
Total Power
(Sum of Rated Power)
1000 Watts RMS
Rated Power
(RMS Continuous Power)
300 Watts x 2 @ 4-Ohm
500 Watts x 2 @ 2-Ohm
1000 Watts x 1 @ 4-Ohm Bridged
Dynamic Power
(PVC/PowerCube®)
401 Watts x 2 @ 4-Ohms 0° Res
656 Watts x 2 @ 2-Ohms 0° Res
Bridgeable
Yes
Frequency Response
20Hz to 20kHz +/- 1.0dB
Input Sensitivity
150 mV - 12 V
Circuit Topology Class
Class A/B
Efficiency (average)
69% @ 4-Ohm
64% @ 2-Ohm
Total Harmonic Distortion (THD+Noise)
4-Ohm: <1.0%
2-Ohm: <1.0%
Signal Input
Hi/Low level: 1 RCA pair
Signal Output
Low level: 1 RCA pair
Tone Controls
Punch EQ2 Bass: 0dB to +18dB @ 45Hz and/or
Punch EQ2 Treble: 0dB to +12dB @ 12.5kHz
Function depends upon LP/AP/HP switch position
Crossover Controls
High-Pass/Low-Pass (HP/LP): 50Hz-250Hz 12dB/octave Butterworth
Remote Controls
Optional Punch Level Control (PLC2) Ready
Visual Indicators
Power/Protect/Thermal LED
Input Clip LED3
Output Clip LED1,2,3

LED Color Legend:
1BLUE: <0.5% THD
2VIOLET: 1% THD
3RED: 10%+ THD
Power Wire Gauge
4 AWG
Power Input Connector
Captive C-Clamp
Speaker Wire Gauge
8 AWG to 18 AWG
Speaker Output Connector
Captive C-Clamp
Cooling
Convection
Heatsink

Operating Voltage
9 - 16 VDC
Recommended Fuse
(not included)
140 A
Average Current Draw (13.8V Music)
70 A
Max. Current Draw (13.8V Sinewave)
140 A
Suggested Alternator
100 A
Included In The Box

Dimensions (H x W x D)
2.38 x 7.76 x 15.03 (in)
6.05 x 19.71 x 38.18 (cm)
Shipping Weight
15 Lbs. (6.80 Kg.)
